Catalog # 305945 - Model 9030 Switch Rack, Power Supply, Cabling

    Switch Rack, Power Supply, Cabling
Click image to enlarge
Base Price:
$445.00
Catalog No: 305945
Model No: 9030
Max. Opening:19" W x 5.25" H x 7" D
Rack Height:5.25"
Comments:Holds 8 modules

Add to Cart
UPS

Shipping Terms

Shipments are made via UPS Ground, unless otherwise specified. Freight charges are prepaid and added to your invoice. We can estimate the freight costs for you.

We can ship freight collect on your account, just provide your UPS Account Number.

We can also ship via the carrier of your choice. Provide the details and your account number.

Products shall be shipped F.O.B. Electro Standards' facility. Title to and risk of loss or damage to the products shall pass to you upon Electro Standards delivery of the products to a carrier for shipment. Title to software will remain with the applicable licensor. Electro Standards' prices do not include shipping and handling charges. Electro Standards reserves the right to use its own discretion in the manner and routing of shipments. Electro Standards shall be permitted to deliver products in separate lots.

Shipping Return Policy

  • To return an item, contact Electro Standards at 401-943-1164 to obtain a Return Material Authorization (RMA) number. RMA numbers are valid for 30 days after the date of the shipment and cannot be extended or re-issued. We are unable to accept returns without an RMA number.
  • All returns except those of defective product are subject to a 15% restocking fee, and additional charges for handling or freight are refunded only in cases of defective products.
  • Return freight must be shipped prepaid. We recommend that you insure the package as you are responsible for risk of loss on all returned packages. We recommend that all cartons are properly packed as Electro Standards is not responsible for product damaged en route. We do not issue call tags for product returns.
  • Returned product must be clean, undamaged, and complete with all manuals, accessories, documents and packaging. The items must be in a resalable condition.
  • The product must have with it a copy of the original invoice or packing slip and the appropriate RMA paperwork.
  • If your item is not working properly, please contact Electro Standards at 401-943-1164 for help in trouble-shooting your application.
  • If the product is defective, Electro Standards will repair or replace that item (at our discretion) upon receipt and evaluation of the original product.
  • Electro Standards reserves the right to authorize product returns after 30 days from the invoice date in some cases. If the product is accepted after 30 days, credit will be issued toward future pruchases only and some additional restocking charges may be applied.
  • All credits from RMAs must be used within one calendar year of issue.

Ask a Question

Send Question

Protected Document Request



Cancel Download Product Manual

Overview

Model 9030 Rack with Power Supply and Cabling

Model 9030 modular rack system shown with the open frame switch module, Model 7009.

SPECIFICATIONS: Model 9030 Rack with Power

  • Rack Size: 19" W x 5.25" H x 7" D. (48.3 x 13.3 x 17.8 cm)
  • Weight: 3.3 lbs (1.5 kg)
  • Power: (Cat No 516274) UL approved 100VAC/240VAC, 50Hz/60Hz wall mount power module supplies 12VDC, 500mA to the unit.  Has 2-prong, US, non-polarized plug.
  • Option: Wide Range Power Module: (Cat No 514296)
  • CE, RoHS, and UL listed table mount power module 100VAC/240VAC, 50Hz/60Hz for use in place of standard power module that is included with the unit. Has IEC 60320 C14 inlet.  Ideal for international applications.

 FEATURES (Model 9030 Rack):

  • The Model 9030 is a 3U, full rack size chassis designed to fit in a standard 19" rack.
  • The Model 9030 modular rack system is sold in conjunction with the open frame modules, Models 7006, 7008, or 7009.
  • The Model 9030 Rack can accommodate up to eight Model 7009 Switch Modules, up to eight Model 7008 Switch Modules, or up to eight Model 7006 Switch Modules.
  • Model 9030 Rack includes a power supply module, which is responsible for powering all the switches in the rack.  A power bus cable (included) distributes the power among the modules.
  • Filler panels are available to attractively cover unused module slots. (See Model 9008, Cat No 305983)
  • Municipalities, schools, government: This product is on GSA Schedule!
  • This high-quality modular rack switch system is available to city, state, and federal government purchasersat a discounted price and favorable payment and shipping terms via GSA Schedule GS-35F-0286V. Click here or on GSA icon for details.

MODEL 7009 CAT5e A/B/OFFLINE SWITCH MODULE APPLICATION w/CONTACT CLOSURE REMOTE: The drawing illustrates one Model 7009 module. The Model 9030 rack can hold up to eight Model 7009 modules.  Each module has a COMMON device connected to the RJ45 COM port accessing two other devices connected to the A and B ports. There are three positions, "A", "B" and "OFFLINE". The OFFLINE position is Secure Mode; no data passes through the switch. The RJ45 Remote port accepts Contact Closure for Remote Control operation. The power bus cable (Cat No 981107) distributes power to all modules from the power supply module included with the Model 9030 rack system.

Model 7009 RJ45 Cat5e A/B/OFFLINE Switch module with Contact Closure Remote

MODEL 7008 CAT5 A/B/OFFLINE SWITCH MODULE APPLICATION w/CONTACT CLOSURE REMOTE: The drawing illustrates one Model 7008 module. The Model 9030 rack can hold up to eight Model 7008 modules.  Each module has a COMMON device connected to the RJ45 COM port accessing two other devices connected to the A and B ports. There are three positions, "A", "B" and "OFFLINE". The OFFLINE position is Secure Mode; no data passes through the switch. The RJ45 Remote port accepts Contact Closure for Remote Control operation. The power bus cable (Cat No 981107) distributes power to all modules from the power supply module included with the Model 9030 rack system.

Model 7008 RJ45 Cat5 A/B/OFFLINE Switch module with Contact Closure Remote

 MODEL 7006 CAT5 A/B/OFFLINE SWITCH MODULE APPLICATION w/RS232 REMOTE: The drawing illustrates one Model 7006 module. The Model 9030 rack can hold up to eight Model 7006 modules.  Each module has a COMMON device connected to the RJ45 COM port accessing two other devices connected to the A and B ports. There are three positions, "A", "B" and "OFFLINE". The OFFLINE position is Secure Mode; no data passes through the switch. The RJ45 Remote port accepts RS232 ASCII Serial data for Remote Control operation. The power bus cable (Cat No 981107) distributes power to all modules from the power supply module included with the Model 9030 rack system.

Model 7006 RJ45 Cat5 A/B/OFFLINE Switch module with RS232 Remote

*Prices online are subject to change and verification.
All ESL products are availabe for export.
