Catalog # 305937 - Model 7009 RJ45 CAT5e A/B/Offline Switch Module

    RJ45 CAT5e A/B/Offline Switch Module
Click image to enlarge
Base Price:
$690.00
Catalog No: 305937
Model No: 7009
Feature:Remote Control/Cat 5e
Switch Type (Fiber, Ethernet, etc.):Ethernet
Positions:A/B/Offline
Channels per Switch/Chassis:1
Chassis/Rack Configuration:Rack Module
Compliance/Category Rating:Cat5e
Connector/Port:RJ45
Pins Switched:8
Remote Control Type:Contact Closure
Remote Control Port:RJ45
Local/Manual Control:Pushbutton

Add to Cart
UPS

Shipping Terms

Shipments are made via UPS Ground, unless otherwise specified. Freight charges are prepaid and added to your invoice. We can estimate the freight costs for you.

We can ship freight collect on your account, just provide your UPS Account Number.

We can also ship via the carrier of your choice. Provide the details and your account number.

Products shall be shipped F.O.B. Electro Standards' facility. Title to and risk of loss or damage to the products shall pass to you upon Electro Standards delivery of the products to a carrier for shipment. Title to software will remain with the applicable licensor. Electro Standards' prices do not include shipping and handling charges. Electro Standards reserves the right to use its own discretion in the manner and routing of shipments. Electro Standards shall be permitted to deliver products in separate lots.

Shipping Return Policy

  • To return an item, contact Electro Standards at 401-943-1164 to obtain a Return Material Authorization (RMA) number. RMA numbers are valid for 30 days after the date of the shipment and cannot be extended or re-issued. We are unable to accept returns without an RMA number.
  • All returns except those of defective product are subject to a 15% restocking fee, and additional charges for handling or freight are refunded only in cases of defective products.
  • Return freight must be shipped prepaid. We recommend that you insure the package as you are responsible for risk of loss on all returned packages. We recommend that all cartons are properly packed as Electro Standards is not responsible for product damaged en route. We do not issue call tags for product returns.
  • Returned product must be clean, undamaged, and complete with all manuals, accessories, documents and packaging. The items must be in a resalable condition.
  • The product must have with it a copy of the original invoice or packing slip and the appropriate RMA paperwork.
  • If your item is not working properly, please contact Electro Standards at 401-943-1164 for help in trouble-shooting your application.
  • If the product is defective, Electro Standards will repair or replace that item (at our discretion) upon receipt and evaluation of the original product.
  • Electro Standards reserves the right to authorize product returns after 30 days from the invoice date in some cases. If the product is accepted after 30 days, credit will be issued toward future pruchases only and some additional restocking charges may be applied.
  • All credits from RMAs must be used within one calendar year of issue.

Ask a Question

Send Question

Protected Document Request



Cancel Download Product Manual

Overview


Path Way® Remotely Controllable Network Switch, Cat5e
Model 7009 RJ45 CAT5e A/B/Off-Line Switch Modules with Contact Closure Remote Control Port

  • 100Base-T, CAT5e Compliant, Modular Expandable System!
  • Absolutely NO data passes through the switch when in the OFFLINE position!
  • The ultimate FIREWALL!

Model 7009 RJ45 Cat5e A/B/Off-Line Switch Module with Contact Closure Remote Port

 SPECIFICATIONS: Each Model 7009 Switch Module

  • PORT CONNECTORS: (3) RJ45 female connectors on rear panel labeled A, B, and COM.
  • LEADS SUPPORTED: All 8 pins switched.
  • CONTROL: (1) Pushbutton on front panel selects A, B, or Off-Line.
  • DISPLAY: (2) Port Status Tri-State LED's on front panel.
  • REMOTE: (1) RJ45 female connector on rear panel accepts contact closure for Remote Control.
  • POWER:  Model 7009 module is powered from the Model 9030 Rack.  Power bus cable (Cat No 981807) distributes power to all modules in the rack.
  • MODULE SIZE: 2" W x 5" H x 7" D. (5.1 x 12.7 x 17.8 cm)
  • WEIGHT: 0.8 lbs. (0.4 kg)

 SPECIFICATIONS: Model 9030 Rack with Power

  • Rack Size: 19" W x 5.25" H x 6.91" D. (48.3 x 13.3 x 17.6 cm)
  • Weight: 3.3 lbs (1.5 kg)
  • Power: (Cat No 516274) UL approved 100VAC/240VAC, 50Hz/60Hz wall mount power module supplies 12VDC, 500mA to the unit.  Has 2-prong, US, non-polarized plug.
  • Option: Wide Range Power Module: (Cat No 514296) CE, RoHS, and UL listed table mount power module 100VAC/240VAC, 50Hz/60Hz for use in place of standard power module that is included with the unit. Has IEC 60320 C14 inlet.  Ideal for international applications.

CAT5e A/B/OFFLINE SWITCH MODULE APPLICATION w/CONTACT CLOSURE REMOTE: The drawing illustrates one Model 7009 module. The Model 9030 rack can hold up to eight Model 7009 modules.  Each module has a COMMON device connected to the RJ45 COM port accessing two other devices connected to the A and B ports. There are three positions, "A", "B" and "OFFLINE". The OFFLINE position is Secure Mode; no data passes through the switch. The RJ45 Remote port accepts Contact Closure for Remote Control operation. The power bus cable (Cat No 981107) distributes power to all modules from the power supply module included with the Model 9030 rack system.

Diagram for Model 7009 RJ45 Cat5e A/B/Offline Network Application

 FEATURES (Model 7009 Switch Modules):

  • The switch ports are transparent to all data.
  • All (8) pins of the RJ45 interface are switched via break-before-make electromechanical relays.
  • The unit maintains last set position on power loss and continues to pass data.
  • Local control via front-panel pushbutton.
  • Remote Contact Closure control and status provide dry contact logic to allow control of the switch position.
  • Jumper allows selection of legacy mode for legacy applications.
  • Front panel LED's display current position and power status.
  • Certified for Cat 5e compliance.
  • The Model 7009 is a modular rack-mount switch and is sold in conjunction with the Model 9030 rack.

FEATURES (Model 9030 Rack):

  • Model 9030 Rack can accommodate up to eight Model 7009 Switch Modules.
  • Model 9030 Rack includes a power supply module, which is responsible for powering all the switches in the rack.  A power bus cable (included) distributes the power among the modules.

 The PathWay® Model 7009 Switch allows the user the capability of accessing two separate devices, ports A and B, via connection through a device connected to the Common port. The switch may be controlled manually via the front panel pushbutton or remotely from the RJ45 Control port located on the rear of the unit.  Switch position state may be attained via the front panel LED.

The Model 9030 Rack with Power Module accommodates up to 8 Model 7009 Switch Modules.  The Model 9030 both holds the Model 7009 modules and provides power to all modules with the included power bus cable.

System Expands to meet your needs!

 This modular approach to switch system requirements allows expansion to more channels on an as-needed basis.  Filler panels are available to attractively cover unused module slots (See Model 9008, Cat No 305983 for 2-inch filler panel)

Expand your system by adding switch modules!

For a Cat5 version, See Model 7008. See Related Products Tab!

Custom Network Switches are available. Contact us by phone, email, or complete the Online Custom Products Form. /Products-Custom/Copper-Switch/

Electro Standards can supply all of your Network Cable requirements. Click here to reach our CABLES, COPPER NETWORK Webpage.

 All data switches, data communication products, and data acquisition products are subject to a one year warranty against manufacturing defects.  The limit of ESL liability is limited to the cost of the ESL product provided.

 *Prices online are subject to change and verification.
All ESL products are available for export.

 Electro Standards welcomes International inquiries: commutateur d'ordinateur,  equipo interruptor, interruttore del calcolatore, interruptor do computador, dator switch.
