Catalog # 304192 - Model 4192 SC A/B/C/D/Off-Line Fiber Switch

    SC A/B/C/D/Off-Line Fiber Switch
Click image to enlarge
Base Price:
$4,795.00
Catalog No: 304192
Model No: 4192
Feature:Off-Line Position
Switch Type (Fiber, Ethernet, etc.):Fiber Optic
Positions:5
Security:Offline Position
Channels per Switch/Chassis:1
Chassis/Rack Configuration:Rackmount
Fiber In/Out Ports:SC/SC
Fiber Mode:Multimode
Fiber Size:62.5/125 micron
Fiber Type:Duplex
Remote Control Type:Voltage Control
Remote Control Port:DB9
Mirror Technology:Yes
Speed:Giga
Wavelength Nano:850
