Catalog # 303184 - Model 4184 SC 100Base-FX A/B Fiber Switch

    SC 100Base-FX A/B Fiber Switch
Click image to enlarge
Base Price:
$1,175.00
Catalog No: 303184
Model No: QuickSwitch 4184 SC A/B
Switch Type (Fiber, Ethernet, etc.):Fiber Optic
Positions:2 (e.g. A/B and Common)
Security:Password Protection
Channels per Switch/Chassis:1
Chassis/Rack Configuration:Desktop
Connector/Port:SC/SC
Fiber In/Out Ports:SC/SC
Fiber Mode:Multimode
Fiber Size:62.5/125 micron
Fiber Type:Duplex
Remote Control Type:RS232 Serial
Remote Control Port:DB9
Mirror Technology:No
Speed:100 Mbps
Wavelength Nano:1300

Add to Cart
UPS

Shipping Terms

Shipments are made via UPS Ground, unless otherwise specified. Freight charges are prepaid and added to your invoice. We can estimate the freight costs for you.

We can ship freight collect on your account, just provide your UPS Account Number.

We can also ship via the carrier of your choice. Provide the details and your account number.

Products shall be shipped F.O.B. Electro Standards' facility. Title to and risk of loss or damage to the products shall pass to you upon Electro Standards delivery of the products to a carrier for shipment. Title to software will remain with the applicable licensor. Electro Standards' prices do not include shipping and handling charges. Electro Standards reserves the right to use its own discretion in the manner and routing of shipments. Electro Standards shall be permitted to deliver products in separate lots.

Shipping Return Policy

  • To return an item, contact Electro Standards at 401-943-1164 to obtain a Return Material Authorization (RMA) number. RMA numbers are valid for 30 days after the date of the shipment and cannot be extended or re-issued. We are unable to accept returns without an RMA number.
  • All returns except those of defective product are subject to a 15% restocking fee, and additional charges for handling or freight are refunded only in cases of defective products.
  • Return freight must be shipped prepaid. We recommend that you insure the package as you are responsible for risk of loss on all returned packages. We recommend that all cartons are properly packed as Electro Standards is not responsible for product damaged en route. We do not issue call tags for product returns.
  • Returned product must be clean, undamaged, and complete with all manuals, accessories, documents and packaging. The items must be in a resalable condition.
  • The product must have with it a copy of the original invoice or packing slip and the appropriate RMA paperwork.
  • If your item is not working properly, please contact Electro Standards at 401-943-1164 for help in trouble-shooting your application.
  • If the product is defective, Electro Standards will repair or replace that item (at our discretion) upon receipt and evaluation of the original product.
  • Electro Standards reserves the right to authorize product returns after 30 days from the invoice date in some cases. If the product is accepted after 30 days, credit will be issued toward future pruchases only and some additional restocking charges may be applied.
  • All credits from RMAs must be used within one calendar year of issue.

Ask a Question

Send Question

Protected Document Request



Cancel Download Product Manual

Overview

QuickSwitch® Fiber Optic Network Switch, SC Duplex
QuickSwitch® 4184 Fiber Optic SC Duplex 100BASE-FX A/B Switch with Remote Port

Model 4184 Fiber Optic SC Duplex 100BASE-FX A/B Switch with Remote Port

  • Provides SC 100BASE-FX Fiber Optic Link Backup

SPECIFICATIONS:

  • PORT CONNECTORS: (3) SC Duplex fiber optic connectors labeled A, B, and COMMON.
  • FIBER OPTIC INTERFACE: Wavelength 1300 nm, speed 100 Mbps, multimode fiber, full duplex transmission, Fiber Size 62.5/125 micron.
  • FRONT PANEL CONTROL: (1) Pushbutton to select port A or B.
  • DISPLAY: (2) Red LEDs display switch position and indicate power presence.
  • SUPERVISORY REMOTE: (1) DB9/female connector on rear panel accepts ASCII RS232 Serial Data for Remote Control operation.
  • POWER: UL approved 115 VAC / 60 Hz, wall mount power module supplies
    12 VDC, 500 mA to the unit.
  • DIMENSIONS: Desktop: 7.5"W x 2.0" H x 7" D. (19.1 x 5.1 x 17.8 cm)
  • WEIGHT: Approx. 2.8 lbs. (1.3 Kg)

SC DUPLEX 100BASE-FX A/B NETWORK TRANSFER APPLICATION: The drawing illustrates an SC Duplex Fiber optic two position switch.  A network connected to the SC Duplex COMMON port can access either of two networks via the SC Duplex Ports A or B. The DB9 Remote port accepts ASCII RS232 Serial Data Commands for Remote Control operation, upon proper authentification (password protected remote).

4184 Fiber Optic SC Duplex 100BASE-FX A/B Switch Network Transfer Application

QuickSwitch® 4184 Fiber Optic SC Duplex Interface AB Switch.  It has a multimode duplex fiber connector interface on the A, B and COMMON ports.  The switch connects a workstation or network between two other devices or networks.  The internal circuitry insures isolation between the A and B devices / networks.  A great solution for fallback network applications.  A front panel button changes the switch position eliminating the need to plug and unplug fiber patchcords thus minimizing connector wear.  Switch position status is displayed on the front panel LEDs.

The unit also includes an RS232 Serial security enhanced Supervisory Remote port.  Upon proper authentication, a terminal or computer in terminal mode connected to this port can communicate with the unit, determine its status, change switch position as desired, and / or lockout front panel switching cabability.  A modem can also be connected to this port for remote access to the switch.  Access to the Supervisory Remote Port feature is password protected.  An optional Graphic User Interface (GUI) software is also available for use with a computer running Windows operating System.

Model 4184 QuickSwitch® Fiber Optic Switch Features:

  • QuickSwitch® 4184 fiber optic network switch allows quick connection to
    any one of two SC networks or devices from one COMMON device.
  • The internal circuitry insures isolation between the devices/networks.
  • Service protocol transparent.
  • Bit-rate and data transparent.
  • Optical data throughput scalability.
  • All fiber ports are SC duplex, multimode, 62.5/125 micron
    and support a wavelength of 1300 nm.
  • Eliminates the need to plug and unplug cables.
  • Local control via front-panel pushbutton.
  • Remote control port allows off-site monitoring and switch management.
  • The Remote port accepts RS232 Serial Data commands for switch position
    control and monitoring.
  • Secure Setup/Configuration access limited by password protection.
  • Front panel pushbutton control can be locked out, remotely.
  • Ideal for fallback applications.
  • Front-panel LED's display switch position and power status.
  • Data will not pass through the unit during power loss.
  • When power is restored, the unit will return to its previous position.
  • Custom length rigorously tested and certified, SC Duplex fiber optic cables
    are available for your switch installation.
  • Municipalities, schools, government:  This product is on GSA Schedule!

Electro Standards can supply all of your Fiber Optic Cable requirements. Please click here to reach our Fiber Optic Cable Webpage.

Order Electro Standards Laboratories Custom Length SC Fiber Optic Cables!
All Electro Standards Labs cables are performance tested and certified!

  1. Click on the QR code for Online Custom Fiber Optic Cable Form
  2. Scan QR Code with your smart phone for phone access.
  3. Click on the DETAILED SPEC icon above on the right for spec sheet
    with the Fiber Optic Cable Form on page 2 to be printed, and faxed.

  Custom Online Fiber Optic Cable Form

To read the article: "HOW TO DETERMINE THE RIGHT FIBER OPTIC NETWORK BACKUP SWITCH FOR YOUR APPLICATION", click link to read as a pdf. You need Acrobat Reader to view this file.

This high-quality network switch is available to city, state, and federal government purchasers at a discounted price and favorable payment and shipping terms via GSA Schedule GS-35F-0286V. Click here or on GSA icon for details.  Electro Standards can supply all of your Fiber Optic Cable requirements. Please click here to reach our Fiber Optic Cable Webpage.
QuickSwitch® ® is a registered trademark of Electro Standards Laboratories.

QuickSwitch® Fiber Optic Switches are available in many configurations: auto fallback, switch/converters, multimode & single mode, and secure off-line positions. Check out our complete line of QuickSwitch® fiber optic switches.

For custom fiber optic network switches contact our friendly sales support staff at 401-943-1164; or email: eslab@electrostandards.com, or complete our On-Line Custom Fiber Optic Switch Form: /Products-Custom/Fiber-Switch/

All data switch boxes, data communication products, and data acquisition products are subject to a one year warranty against manufacturing defects.  The limit of ESL liability is limited to the cost of the ESL product provided.

 *Prices online are subject to change and verification. All ESL products are available for export.
