Catalog # 307368 - Model 7368 2-Channel Piezo-Cell Overcurrent Switch

    2-Channel Piezo-Cell Overcurrent Switch
Click image to enlarge
Base Price:
$805.00
Catalog No: 307368
Model No: 7368
Switch Type (Fiber, Ethernet, etc.):Coax/BNC
Positions:2 (e.g. A/B and Common)
Channels per Switch/Chassis:2
Chassis/Rack Configuration:Desktop
Connector/Port:BNC
Pins Switched:Both center conductor and shield
Local/Manual Control:Pushbuttons

Add to Cart
UPS

Shipping Terms

Shipments are made via UPS Ground, unless otherwise specified. Freight charges are prepaid and added to your invoice. We can estimate the freight costs for you.

We can ship freight collect on your account, just provide your UPS Account Number.

We can also ship via the carrier of your choice. Provide the details and your account number.

Products shall be shipped F.O.B. Electro Standards' facility. Title to and risk of loss or damage to the products shall pass to you upon Electro Standards delivery of the products to a carrier for shipment. Title to software will remain with the applicable licensor. Electro Standards' prices do not include shipping and handling charges. Electro Standards reserves the right to use its own discretion in the manner and routing of shipments. Electro Standards shall be permitted to deliver products in separate lots.

Shipping Return Policy

  • To return an item, contact Electro Standards at 401-943-1164 to obtain a Return Material Authorization (RMA) number. RMA numbers are valid for 30 days after the date of the shipment and cannot be extended or re-issued. We are unable to accept returns without an RMA number.
  • All returns except those of defective product are subject to a 15% restocking fee, and additional charges for handling or freight are refunded only in cases of defective products.
  • Return freight must be shipped prepaid. We recommend that you insure the package as you are responsible for risk of loss on all returned packages. We recommend that all cartons are properly packed as Electro Standards is not responsible for product damaged en route. We do not issue call tags for product returns.
  • Returned product must be clean, undamaged, and complete with all manuals, accessories, documents and packaging. The items must be in a resalable condition.
  • The product must have with it a copy of the original invoice or packing slip and the appropriate RMA paperwork.
  • If your item is not working properly, please contact Electro Standards at 401-943-1164 for help in trouble-shooting your application.
  • If the product is defective, Electro Standards will repair or replace that item (at our discretion) upon receipt and evaluation of the original product.
  • Electro Standards reserves the right to authorize product returns after 30 days from the invoice date in some cases. If the product is accepted after 30 days, credit will be issued toward future pruchases only and some additional restocking charges may be applied.
  • All credits from RMAs must be used within one calendar year of issue.

Ask a Question

Send Question

Protected Document Request



Cancel Download Product Manual

Overview

Model 7368 Dual-Channel Piezo-Cell Overcurrent Protection Switch

Model 7368 Dual Channel Piezo-Cell Overcurrent Protection Switch

The Model 7368 Dual Channel Piezo-Cell Overcurrent Protection Switch monitors the peak current flow in up to 2 channels simultaneously.  The basic function is to switch off the current flow if the peak value exceeds the user specified maximum.  The unit normally operates stand alone but is capable of being remotely configured via RS232 serial data communication interface.

Features:

  • Supports simultaneous testing of two capacitors.
  • As an option, this design can be expanded to support testing of more than
    two capacitors in the test platform.  Call for quote.
  • Remote control operation is available via RS232 serial data.
  • Switches both center conductor and shield of the BNC connectors.
  • Common input signal.
  • Maximum peak input voltage with load attached is 55 millivolts.
  • Maximum current flow is 13.7 mA.
  • Selectable maximum allowed peak current (0 - 13.7mA)
  • Fault indicator LED for each channel.
  • Fault reset button for each channel.
  • User configuration menu available from unit via serial terminal emulators
    (hyper-terminal or Tera Term) configurations are detailed in User's Manual.
  • Selectable maximum number of threshold violations before a fault is declared.
  • ADC calibration (Analog-to-Digital Converter).
  • Selectable sampling filter size (1-1000).
  • Press any key on serial terminal to stop current monitor mode.
  • Display instantaneous currents on any calibrated channel.
  • USB port on rear panel for future use (not active).

Specifications:

  • PORT CONNECTORS:  (3) BNC(F) connectors labeled COM-IN, OUT-A, and OUT-B
  • FRONT PANEL CONTROL: (3) Pushbuttons labeled RESET A, RESET B, and SPARE.
  • DISPLAY: (4) LED's labeled RESET A, RESET B, RESERVED, and SERIAL.
  • REMOTE CONTROL:  (1) DB9(F) connector accepts RS232 serial data to control unit operational parameters, and reset of fault display.
  • POWER: "Wide Range" CE and UL listed table mount power module (Cat. No. 521091) 100VAC/240VAC, 50Hz/60Hz supplies 5VDC, 3.0A to the unit.  Ideal for international applications.
  • DIMENSIONS: Desktop: 7.25" W x 2.75" H x 9.5" D. (18.4 x 7.0 x 24.1 cm)
  • WEIGHT: Approximately 2.7 lbs. (1.2 Kg)

APPLICATION: Overcurrent switch application supports simultaneous testing of two capacitors.  DB9 Remote accepts ASCII RS232 Serial data commands for Remote Control Operation.

Network Application Diagram of Model 7368 Dual Channel Piezo-Cell Overcurrent Protection Switch

  Custom Network Switches are available. Contact us by phone, email, or complete the Online Custom Products Form. /Products-Custom/Copper-Switch/

Electro Standards can supply all of your Network Cable requirements. Click here to reach our CABLES, COPPER NETWORK Webpage.

All data switches, data communication products, and data acquisition products are subject to a one year warranty against manufacturing defects.  The limit of ESL liability is limited to the cost of the ESL product provided.
 *Prices online are subject to change and verification.
All ESL Network Switches are available for export.
