Catalog # 306277 - Model 6277 Online/Offline Fiber Switch

    Online/Offline Fiber Switch
Click image to enlarge
Base Price:
$1,280.00
Catalog No: 306277
Model No: 6277
Switch Type (Fiber, Ethernet, etc.):Fiber Optic
Positions:2, OFFLINE/ONLINE
Channels per Switch/Chassis:1
Chassis/Rack Configuration:Rackmount
Fiber In/Out Ports:SC/SC
Fiber Mode:Multimode
Fiber Size:62.5/125 micron
Fiber Type:Duplex
Mirror Technology:Yes
Wavelength Nano:850 nm

Add to Cart
UPS

Shipping Terms

Shipments are made via UPS Ground, unless otherwise specified. Freight charges are prepaid and added to your invoice. We can estimate the freight costs for you.

We can ship freight collect on your account, just provide your UPS Account Number.

We can also ship via the carrier of your choice. Provide the details and your account number.

Products shall be shipped F.O.B. Electro Standards' facility. Title to and risk of loss or damage to the products shall pass to you upon Electro Standards delivery of the products to a carrier for shipment. Title to software will remain with the applicable licensor. Electro Standards' prices do not include shipping and handling charges. Electro Standards reserves the right to use its own discretion in the manner and routing of shipments. Electro Standards shall be permitted to deliver products in separate lots.

Shipping Return Policy

  • To return an item, contact Electro Standards at 401-943-1164 to obtain a Return Material Authorization (RMA) number. RMA numbers are valid for 30 days after the date of the shipment and cannot be extended or re-issued. We are unable to accept returns without an RMA number.
  • All returns except those of defective product are subject to a 15% restocking fee, and additional charges for handling or freight are refunded only in cases of defective products.
  • Return freight must be shipped prepaid. We recommend that you insure the package as you are responsible for risk of loss on all returned packages. We recommend that all cartons are properly packed as Electro Standards is not responsible for product damaged en route. We do not issue call tags for product returns.
  • Returned product must be clean, undamaged, and complete with all manuals, accessories, documents and packaging. The items must be in a resalable condition.
  • The product must have with it a copy of the original invoice or packing slip and the appropriate RMA paperwork.
  • If your item is not working properly, please contact Electro Standards at 401-943-1164 for help in trouble-shooting your application.
  • If the product is defective, Electro Standards will repair or replace that item (at our discretion) upon receipt and evaluation of the original product.
  • Electro Standards reserves the right to authorize product returns after 30 days from the invoice date in some cases. If the product is accepted after 30 days, credit will be issued toward future pruchases only and some additional restocking charges may be applied.
  • All credits from RMAs must be used within one calendar year of issue.

Ask a Question

Send Question

Protected Document Request



Cancel Download Product Manual

Overview

QuickSwitch® Fiber Optic Network Switch, SC Duplex
QuickSwitch® 6277 Fiber Optic SC Duplex Online/Offline Switch

  • Quick Connect/Disconnect to/from network.
  • Absolutely NO DATA passes when switch is in the OFFLINE position.
  • The Ultimate FIREWALL!

QuickSwitch® 6277 Single Channel SC Duplex Online/Offline Fiber Optic Switch

SPECFICATIONS:

  • PORT CONNECTORS: (2) SC Duplex female connectors labeled IN and OUT.
  • FIBER SIZE: 62.5/125 micron, 850 nm.
  • FRONT PANEL CONTROL: (1) Manual pushbutton allows local switching.
  • DISPLAY: (2) Front-panel LED's display switch position and power status.
  • NO REMOTE CONTROL.
  • POWER: UL approved 100VAC/240VAC, 50 Hz/60 Hz wall mount power module supplies 12VDC 500mA to the unit. Has 2-prong, US, non-polarized plug.
  • DIMENSIONS: Rackmount, 19.0" W x 1.75" H x 8.78" D (48.3 x 4.4 x 22.4 cm)
  • WEIGHT: Approximately 4.1 lbs. (1.9 kg).

SC DUPLEX  MULIT-MODE ONLINE/OFFLINE FIBER OPTIC NETWORK APPLICATION:
The drawing illustrates a Fiber Optic Network connected to the SC Duplex Multimode IN port and a Fiber Optic Network connected the the SC Duplex Multimode OUT port. When the ONLINE position is selected the Fiber Optic Networks are connected. When the OFFLINE postion is selected the Fiber Optic Networks are disconnected and NO DATA passes.

QuickSwitch® 6277 ONLINE/OFFLINE APPLICATION Drawing

 QuickSwitch® 6277 Features:

  • Allows quick connection or disconnection between two fiber optic networks or devices.
  • The switch ports are transparent to all data.
  • All fiber signals are switched via break-before-make MEMS-based mirror/prism switch technology.
  • Switch maintains position on power loss and continue to pass data.
  • "OFFLINE" switch position stops any and all data throughput for the unit.
  • Front panel pushbutton control. No Remote Control.
  • Front panel LED's display present position and power status.
  • All IN and OUT ports are SC Duplex, Multi-mode, 62.5/125 micron, and suppport a wavelength of 850nm.
  • The fiber ports are configured per TIA/EIA-568-B.3, where the TX of the COM port is routed to the RX of the A/B ports and vice versa.
  • Optical data throughput scalability.
  • Eliminates need to plug/unplug fiber optic patchcords.
  • Custom length rigorously tested and certified, SC fiber optic cables available for your switch installation.

The QuickSwitch® 6277 Single Channel SC Duplex Online/Offline Switch allows the user the capability of connecting or disconnecting two separate devices connected to ports IN and OUT.  All switch position control is via the front panel pushbutton. The QuickSwitch® 6277 is enclosed in a 1U, full rack size, all metal black chassis designed to fit in a standard 19" rack.

 This high-quality network switch is available to city, state, and federal government purchasers at a discounted price and favorable payment and shipping terms via GSA Schedule GS-35F-0286V. Click here or on GSA icon for details.

 Customize Your Fiber Optic Switch by clicking here.

Electro Standards can supply all of your Fiber Optic Cable requirements. Please click here to reach our Fiber Optic Cable Webpage.

 QuickSwitch® ® is a registered trademark of Electro Standards Laboratories.

QuickSwitch® Fiber Optic Switches are available in many configurations: auto fallback, switch/converters, multimode & single mode, and secure off-line positions. Interfaces include: SC, ST, LC, and ESCON. Check out our complete line of QuickSwitch® fiber optic switches.

 For custom fiber optic network switches contact our friendly sales support staff at 401-943-1164; or email: eslab@electrostandards.com, or complete our On-Line Custom Fiber Optic Switch Form: /Products-Custom/Fiber-Switch/

All data switch boxes, data communication products, and data acquisition products are subject to a one year warranty against manufacturing defects.  The limit of ESL liability is limited to the cost of the ESL product provided.

*Prices online are subject to change and verification.
All ESL products are availabe for export.

Electro Standards welcomes International inquiries: commutateurs à fibres optiques, interruptores de fibra óptica, switch in fibra ottica, switches de fibra óptica, fiberoptiska switcher.
