Catalog # 305533 - Model 5533 Display For Model 5534 4-State Secure Switch

    OFF/SVCN/JSIS/GPCN Display For 5534
Click image to enlarge
Base Price:
$705.00
Catalog No: 305533
Model No: 5533
Positions:4
Chassis/Rack Configuration:Rackmount

Add to Cart
UPS

Ask a Question

Send Question

Protected Document Request



Cancel Download Product Manual

Overview

  Video Conference Room Switch, Display Indicators
 Model 5533 OFF/SVCN/JSIS/GPCN Display Indicator Unit

Use with Model 5534 4-State Cat5e RJ45 Switch to Create a Robust Conference Communications Switching System.  Great for Video Conference Rooms!


 Model 5533 OFF/SVCN/JSIS/GPCN Display Indicator for Model 5534 Switch

Model 5533 OFF/SVCN/JSIS/GPCN Display Indicator for Model 5534 Switch App Note



The Model 5533 is designed to display the isolation/connection status of communications equipment.  This equipment comprises a switching system that includes the Model 5534 Single Channel 4-State Cat5e switch.  Users can link these units to create a robust conference communications switching system.  The dimensions of the Model 5533 are 1.75"H x 8"D x 19"W and the unit mounts in a standard 1U equipment rack.  The unit weight is approximately 2.0 lbs.

Model 5533 Display Indicator Unit showing the GPCN position
of the Model 5534, Cat. No. 305534

Model 5533 OFF/SVCN/JSIS/GPCN Display Indicator for Model 5534 Switch

Model 5533 Display Indicator Unit showing the JSIS position
of the Model 5534, Cat. No. 305534
 Model 5533 OFF/SVCN/JSIS/GPCN Display Indicator for Model 5534 Switch

Model 5533 Display Indicator Unit showing the SVCN position
of the Model 5534, Cat. No. 305534
 Model 5533 OFF/SVCN/JSIS/GPCN Display Indicator for Model 5534 Switch

 FEATURES:
  • Large display of important isolation/connection status of secure communication networks, including secure Offline position (OFF).
  • The front panel LED Display on the Model 5533 will display the OFF/SVCN/JSIS/GPCN status of the switch system.
  • Has a DB9(F) Control port for linking the Model 5533 Display Unit to the Model 5534 Switch that it is monitoring.
  • This unit also supplies power to the LED's of the companion Model 5534 Switch.
  • UL and CE approved wall mount power module supplies 12VDC, 500mA to the Display Indicator Unit.
  • Installs in a standard 19" wide equipment rack.



Custom Network Switches are available. Contact us by phone, email, or complete the Online Custom Products Form. /Products-Custom/Copper-Switch/

 Electro Standards can supply all of your Network Cable requirements. Click here to reach our CABLES, COPPER NETWORK Webpage.


All data switch boxes, data communication products, and data acquisition products are subject to a one year warranty against manufacturing defects.  The limit of ESL liability is limited to the cost of the ESL product provided.
*Prices online are subject to change and verification.
All ESL Secure Offline Switches are available for export
