Catalog # 304292 - Model 4292 LC A/B/C/D/OFFLINE Fiber Switch

    LC A/B/C/D/OFFLINE Fiber Switch
Click image to enlarge
Base Price:
$5,475.00
Catalog No: 304292
Model No: 4292
Switch Type (Fiber, Ethernet, etc.):Fiber Optic
Positions:5
Security:Offline Position
Channels per Switch/Chassis:1
Chassis/Rack Configuration:Rackmount
Fiber In/Out Ports:LC/LC
Fiber Mode:Multimode
Fiber Size:50/125 micron
Fiber Type:LC Duplex
Remote Control Type:RS232 Serial
Remote Control Port:DB9
Mirror Technology:Yes
Wavelength Nano:850nm

Add to Cart
UPS

Shipping Terms

Shipments are made via UPS Ground, unless otherwise specified. Freight charges are prepaid and added to your invoice. We can estimate the freight costs for you.

We can ship freight collect on your account, just provide your UPS Account Number.

We can also ship via the carrier of your choice. Provide the details and your account number.

Products shall be shipped F.O.B. Electro Standards' facility. Title to and risk of loss or damage to the products shall pass to you upon Electro Standards delivery of the products to a carrier for shipment. Title to software will remain with the applicable licensor. Electro Standards' prices do not include shipping and handling charges. Electro Standards reserves the right to use its own discretion in the manner and routing of shipments. Electro Standards shall be permitted to deliver products in separate lots.

Shipping Return Policy

  • To return an item, contact Electro Standards at 401-943-1164 to obtain a Return Material Authorization (RMA) number. RMA numbers are valid for 30 days after the date of the shipment and cannot be extended or re-issued. We are unable to accept returns without an RMA number.
  • All returns except those of defective product are subject to a 15% restocking fee, and additional charges for handling or freight are refunded only in cases of defective products.
  • Return freight must be shipped prepaid. We recommend that you insure the package as you are responsible for risk of loss on all returned packages. We recommend that all cartons are properly packed as Electro Standards is not responsible for product damaged en route. We do not issue call tags for product returns.
  • Returned product must be clean, undamaged, and complete with all manuals, accessories, documents and packaging. The items must be in a resalable condition.
  • The product must have with it a copy of the original invoice or packing slip and the appropriate RMA paperwork.
  • If your item is not working properly, please contact Electro Standards at 401-943-1164 for help in trouble-shooting your application.
  • If the product is defective, Electro Standards will repair or replace that item (at our discretion) upon receipt and evaluation of the original product.
  • Electro Standards reserves the right to authorize product returns after 30 days from the invoice date in some cases. If the product is accepted after 30 days, credit will be issued toward future pruchases only and some additional restocking charges may be applied.
  • All credits from RMAs must be used within one calendar year of issue.

Ask a Question

Send Question

Protected Document Request



Cancel Download Product Manual

Overview

QuickSwitch® Fiber Optic Network Switch, LC Duplex
QuickSwitch® 4292 Single Channel LC Duplex A/B/C/D/Off-Line Switch, with RS232 Remote
 LC Duplex A/B/C/D Off-Line Fiber Optic Switch, RS232 Serial Remote, Model 4292

SPECIFICATIONS:

  • FIBER: LC multimode, 50/125 micron, wavelength 850 nm.
  • PORT CONNECTORS: (5) LC duplex female connectors, labeled A, B, C, D and COMMON.
  • FRONT PANEL CONTROLS: (5) Manual pushbuttons allow local switching.
  • DISPLAY: (5) Front-panel LED's display switch position, and power status.
  • REMOTE CONTROL: (1) DB9 female connector on rear panel accepts ASCII RS232 Serial Data for Remote Control operation.
  • POWER: UL Approved 100 VAC/240VAC, 50Hz/60Hz wall mount power module supplies 12 VDC, 500 mA to the unit. Has 2-prong, US, non-polarized plug.
  • DIMENSIONS: 19.0" W x 1.75" H x 10.0" D (48.3 x 4.4 x 25.4 cm)
  • WEIGHT: Approximately 5.5 lbs. (2.5 Kg)

LC DUPLEX A/B/C/D/OFFLINE APPLICATION WITH PASSWORD PROTECTED RS232 REMOTE: The drawing illustrates a COMMON device connected to the LC Duplex COMMON port accessing four other devices connected to the LC Duplex A, B, C, D ports. The user can also select and OFFLINE position which stops any and all data throughput the unit. The DB9 Remote port is PASSWORD PROTECTED and can be disabled. The unit can be controlled remotely via ASCII RS232 commands to control switch position, lockout front panel operations, and obtain switch status.

 LC Duplex Fiber Optic Switch Secure Off-Line position, RS232 Remote Control, Model 4292 Diagram

The QuickSwitch® 4292 Single Channel LC Duplex A/B/C/D/Off-Line Switch with RS232 Remote allows the user the capability of sharing a single port interface device connected to the COMMON port among four other devices connected to the A, B, C, and D ports, or to isolate all ports in the OFFLINE position.

Remote access can be accomplished using a DB9 RS232 connection and ASCII serial commands.  The QuickSwitch® 4292 is enclosed in a 1U, full rack size, black anodized chassis designed to provide EMI/RFI shielding and fit in a standard 19" rack.

 Features:

  • Allows quick connection to any one of four devices from one COMMON device.
  • MEMS-based mirror/prism switch technology supports Gigabit data rates.
  • Service protocol transparent.
  • Bit-rate and data transparent.
  • All fiber ports are LC duplex, multimode 50/125 micron and support a wavelength of 850 nm.
  • Local control via front-panel pushbuttons.
  • Remote RS232 ASCII commands that allow the user to control switch position, lockout front panel operations, and obtain switch status.
  • Remote control of the switch is password protected, where the password protection can be disabled.
  • Front-panel LED's display switch position and power status.
  • When power is lost, unit will switch to OFFLINE position and stop passing data.
  • When power is restored, unit will remain in OFFLINE position until commanded to change.
  • OFFLINE switch position stops any and all data throughput for the unit.
  • Custom length rigorously tested and certified, LC fiber optic cables available for your switch installation.

Wide Range Power Option Available: (Cat No 517277) CE, RoHS, and UL listed table mount power module, 100 VAC/240 VAC, 50Hz/60Hz in place of standard power module.  Has IEC 60320 C14 inlet. Ideal for international applications.

QuickSwitch® ® is a registered trademark of Electro Standards Laboratories.

QuickSwitch® Fiber Optic Switches are available in many configurations: auto fallback, switch/converters, multimode & single mode, and secure off-line positions. Check out our complete line of QuickSwitch® fiber optic switches.

For custom fiber optic network switches contact our friendly sales support staff at 401-943-1164; or email: eslab@electrostandards.com, or complete our On-Line Custom Fiber Optic Switch Form: /Products-Custom/Fiber-Switch/

Electro Standards can supply all of your Fiber Optic Cable requirements. Please click here to reach our Fiber Optic Cable Categories Webpage:
/Products-By-Category/?catid=33&category=Cables, Fiber Optic Network&filter=

All data switch boxes, data communication products, and data acquisition products are subject to a one year warranty against manufacturing defects.  The limit of ESL liability is limited to the cost of the ESL product provided.

 *Prices online are subject to change and verification.
All ESL products are available for export.
