304119 - 4119 ST Fiber-to-USB Converter/Extender, 4-Port Hub

    Converter/Extender, 4-Port Hub
Click image to enlarge
Base Price:
$1,035.00
Catalog No: 304119
Model No: 4119
Feature:Ruggedized against shock and vibration
Chassis/Rack Configuration:Desktop
Connector/Port:USB Type A/Fiber Optic ST
Convert To:USB
Convert From:ST Fiber
Fiber Size:50/125, 62.5/125
Speed:up to 480 Mbps
Wavelength Nano:850 mn, multimode

Add to Cart
UPS

Shipping Terms

Shipments are made via UPS Ground, unless otherwise specified. Freight charges are prepaid and added to your invoice. We can estimate the freight costs for you.

We can ship freight collect on your account, just provide your UPS Account Number.

We can also ship via the carrier of your choice. Provide the details and your account number.

Products shall be shipped F.O.B. Electro Standards' facility. Title to and risk of loss or damage to the products shall pass to you upon Electro Standards delivery of the products to a carrier for shipment. Title to software will remain with the applicable licensor. Electro Standards' prices do not include shipping and handling charges. Electro Standards reserves the right to use its own discretion in the manner and routing of shipments. Electro Standards shall be permitted to deliver products in separate lots.

Shipping Return Policy

  • To return an item, contact Electro Standards at 401-943-1164 to obtain a Return Material Authorization (RMA) number. RMA numbers are valid for 30 days after the date of the shipment and cannot be extended or re-issued. We are unable to accept returns without an RMA number.
  • All returns except those of defective product are subject to a 15% restocking fee, and additional charges for handling or freight are refunded only in cases of defective products.
  • Return freight must be shipped prepaid. We recommend that you insure the package as you are responsible for risk of loss on all returned packages. We recommend that all cartons are properly packed as Electro Standards is not responsible for product damaged en route. We do not issue call tags for product returns.
  • Returned product must be clean, undamaged, and complete with all manuals, accessories, documents and packaging. The items must be in a resalable condition.
  • The product must have with it a copy of the original invoice or packing slip and the appropriate RMA paperwork.
  • If your item is not working properly, please contact Electro Standards at 401-943-1164 for help in trouble-shooting your application.
  • If the product is defective, Electro Standards will repair or replace that item (at our discretion) upon receipt and evaluation of the original product.
  • Electro Standards reserves the right to authorize product returns after 30 days from the invoice date in some cases. If the product is accepted after 30 days, credit will be issued toward future pruchases only and some additional restocking charges may be applied.
  • All credits from RMAs must be used within one calendar year of issue.

Ask a Question

Send Question

Protected Document Request



Cancel Download Product Manual

Overview

Model 4119 High Speed ST Fiber-to-USB Converter/Extender, 4-Port USB Hub, Desktop Configuration

  • Simultaneously connect up to four USB Interface Devices to your desktop PC or notebook.
  • High speed connection to distant USB devices over multimode fiber optic cable.

Model 4119 / 4119-DIN 4-Port Hub for use with the Model 4112-4112-DIN Host

The desktop Model 4119 is a 4-Port USB Hub that works with desktop Model 4112 Host (also see related products tab for M4112 details) to comprise a Host and a Four Port USB Wired Hub that extend USB connections up to 500 meters via a high speed Fiber interface.

Two configurations are available for each model
(see Related Products tab):
(1) Model 4112 Host Desktop Unit, for applications requiring an enclosure.
(2) Model 4112-DIN Host Unit for applications requiring mounting on a DIN rail.
(3) Model 4119 4-Port USB Hub Desktop Unit, for applications requiring an enclosure.
(4) Model 4119-DIN 4-Port USB Hub Unit for applications requiring mounting on a DIN rail.

Network Application Diagram for Model 4119 ST Fiber-to-USB 4-Port Hub

 FEATURES:

  • Convert USB 2.0 compliant data from a standard PC Host interface, Model 4112, over fiber to a remote 4-Port powered USB Hub, Model 4119.
  • Ideal for applications involving PC communication that require high speed, secure communication, and optical isolation.
  • Extend USB communication in environments that are subject to high EM or RF interference that might corrupt communication over a copper interface.
  • Typical applications include industrial control, KVM extension, remote desktop USB connections, and remote USB device sharing such as printers, scanners and storage devices.
  • Units offer true plug and play operability with support for Windows®, Mac OS®, Linux®, and support all USB device types: Control, Interrupt, Bulk and Isochronous up to 480 Mbps.
  • Designed to operate from -0 degree C to +50 degree C (component ratings meet or exceed 0° C to 70° C).
  • Units feature ESD protection circuitry on all copper USB I/O interfaces, per IEC 61000-4-2 standard.
  • Power inputs are protected from overvoltage, overcurrents and high power  transients.
  • The 4-port USB Hub provides the USB standard of 500mA per port.
  • LEDs display Power, Fiber Link Active, Host Active (Model 4112, 4112-DIN) and Port Active (Model 4119, 4119-DIN) indicator LEDs.

SPECIFICATIONS:

USB Interface
 Connectors: Model 4112 - 1x USB Type B, High Retention
                    Model 4119 - 4x USB Type A,
                    (5V @500mA/port)

                    Model 4112-DIN - 1x USB Type B, High Retention
                    Model 4119-DIN - 4x USB Type A,
                    (5V @500mA/port)

USB Data Format:
  Type: USB 2.0 Compliant (Backwards compatible USB 1.1)
   Rate: Supports Low Speed (1.5 Mbps),
            Full Speed (12 Mbps), and High Speed
            (480 Mbps) USB Data transfer rates.

Fiber Interface:
  Connectors: Fiber Optic ST
  TX Power: -6.5 dBm (Typical)
  RX Sensitivity: -21.5 dB (Typical)
  Optical Budget:  14.5 dB
  Max. Link Distance with 50/125 µm fiber: 500 Meters
  Max. Link Distance with 62.5/125 µm fiber: 275 Meters
  Wavelength: 850 nm, multimode

 LED Indicators:
             Model 4112 - Power, Fiber Link Active, Host Active
             Model 4119 - Power, Fiber Link Active, Port Active

            Model 4112-DIN - Power, Fiber Link Active, Host Active
            Model 4119-DIN - Power, Fiber Link Active, Port Active

Input Power: Requirement
                     Model 4112 - 5VDC @ 2.5W
                     Model 4119 - 5VDC @ 15W

                     Model 4112-DIN - 5VDC @ 2.5W
                     Model 4119-DIN - 5VDC @ 15W

Power Connector:
On all models, the input power connector is a DC power jack (Circular Barrel Type).

External Power Supply
The power supply is not included with any of the units and can be ordered separately, ESL Cat. No. 524450.

Operating Environment:
  Tested operation, 0°C to +50°C; component ratings
   meet or exceed 0°C to 70°C.

Model 4112 Mechanical (Desktop Unit):
  Model 4112, Cat No 304112
  Size: 4.27" W x 1.35" H x 9.44" (10.9 x 3.5 x 24.0 cm)
  Weight:  Approx. 1.2 lbs (528g)
  Mounting: Desktop Std, DIN rail (Optional)

Model 4119 Mechanical (Desktop Unit):
  Model 4119 Cat No 304119
  Size: 4.27" W x 1.35" H x 9.44" (10.9 x 3.5 x 24.0 cm)
  Weight:  Approx. 1.2 lbs (528g)
   Mounting: Desktop Std, DIN rail (Optional)

Model 4112-DIN Mechanical (DIN Rail Mounted Unit):
  Model 4112-DIN Cat No 304112-DIN
  Size: 4.27" W x 1.35" H x 9.44" (10.9 x 3.5 x 24.0 cm)
  Weight:  Approx. 1.2 lbs (528g)
  Mounting: 2 Threaded Holes Standard, DIN rail
  DIN Rail Bracket Size: 2.84" x 1.24" x 0.16"
  DIN Rail Bracket Weight: 0.9 oz (25.5g)

Model 4119-DIN Mechanical (DIN Rail Mounted Unit):
  Model 4119-DIN Cat No 304119-DIN
  Size: 4.27" W x 1.35" H x 9.44" (10.9 x 3.5 x 24.0 cm)
  Weight:  Approx. 1.2 lbs (528g)
  Mounting: 2 Threaded Holes Standard, DIN rail
  DIN Rail Bracket Size: 2.84" x 1.24" x 0.16"
  DIN Rail Bracket Weight: 0.9 oz (25.5g)

 USB A-B Cable (6 Ft): Included with Model 4112 / 4112-DIN is the cable ESL Cat. No. 507366 (USB Type A to USB Type B)

All data switches, fiber optic converters, data communication products, and data acquisition products are subject to a one year warranty against manufacturing defects.  The limit of ESL liability is limited to the cost of the ESL product provided.

*Prices of Fiber Optic Interface Converters are subject to change and verification.

All ESL Fiber Optic Converters are available for export.
